Fluorescent inspection system

More efficient and economical inspection systems

Fluorescent penetrant inspection systems, with that a large amount of test objects can be inspected efficiently and economically, have been widely used for precise inspections of various types of parts including those in the aviation industry. NEOGLO-UNITS have been designed and madeto satisfy users’ needs adequately by making full use of “know- how “cultivated in long-term experiences and abundant sales achievements.

Eishin’s & J.N.S. (2003) penetrant inspection systems are mainly divided into fourtypes.Test objectsaretransferredmanuallyby handor with hoists. Automatic system is also available. Every inspection process can be automated from penetration to inspection,andthe test objects are transferred automatically.

Specifications

EF-A type system

Small-sized penetrant testing system (about 5m in total length) for small and light weight test objects. Basically, test objects aremanually transferred between the stations.

EF-B type system

Medium-sized penetrant testing system (about 10m in total length) for large and heavy weight test objects. Usually, test objects are transferred on the roller conveyer between the stations. Each station is equipped with a lifter or a door.

EF-C type system

Large-sized penetrant testing system (more than 10m in total length) for mass-produced parts. The test objects are automatically transferred on the independently-driving roller or chain conveyer.

EF-D type system

EF-D type system is equipped with the waste water treatment system dedicated to separate-type water washable fluorescent penetrants. Rinse water can be recycled with this system.

  • Waste water treatment systems for standard penetrants (MIZUSUMASHI)are also available.
  • Custom-designed system is available.

Inspection

Procedures for fluorescent penetrant inspection

Fluorescent penetrant inspections may be performed in three methods. Select any of these methods and the type of the penetrant to be used depending on the material type of test objects, the surface condition and the defect type.

Read More

Magnetic particle inspection materials

MAGNATRON gives a good contrast of any defects against the background and has high sensitivity. The desired one can be selected out of abundant types. And also, BLENDEX and MAGNATRON OIL can suspend magnetic particles very well.

  • MAGNATRON gives a good contrast of any defects against

Specifications

Magnetic particles

Fluorescent magnetic particles

Fluorescent magnetic particles show brilliant fluorescent under black light. Even a lower concentration of suspension, 1g/liter, achieves higher sensitivity.

TYPE Application PARTICLE SIZE(μm) RECOMMENDED CONCENTRATION(g/l) VOLUME OF SETTLED PARTICLES(ml)
SY-6000 Raw materials 5-30 0.5-2.0 0.04-0.12
SY-7000 General inspection 5-20 0.3-2.0 0.02-0.12
SY-7000S General or semi-precision inspection 1-15 0.3-2.0 0.04-0.21
SY-7500 Semi-precision inspection 2-5 0.3-2.0 0.03-0.20
SY-8000 Precision inspection Less than 3 0.1-2.0 0.02-0.50
SY-8000A/1 Precision inspection Less than 3 0.1-2.0 0.02-0.50

HIGH Brightness TYPE

TYPE Application PARTICLE SIZE(μm) RECOMMENDED CONCENTRATION(g/l) VOLUME OF SETTLED PARTICLES(ml)
SY-6000Br General inspection 1-15 0.3-2.0 0.03-0.20
SY-6300 General inspection 1-10 0.1-2.0 0.02-0.25
SY-8500 Precision inspection 1-7 0.1-2.0 0.02-0.32

Aerosol type

Aerosol cans in which a correct amount of fluorescent magnetic particle is suspended in an oil. Simply spraying detects any defects quickly. Three types of particles are provided: SY-7500, SY-7500Special,SY-8000, and SY-8000XB. In addition, Water-based SY-8000W is offered.

Premixed type

Premixed fluorescent magnetic particles with conditioning powder. Simply by putting a predefined amount of particles into water and stirring, the solution can be easily prepared. Two types are provided: SY-7500WS-3 and SY-7000SP.

Non-fluorescent magnetic particles

Wet type

Select any type considering color, contrast against the background, and conditions to be used. This type is used for observing under white light.

COLOR TYPE COLOR TONE Application PARTICLE SIZE(μm) RECOMMENDED CONCENTRATION(g/l) VOLUME OF SETTLED PARTICLES(ml)
Red MA-30 Reddish Brown General inspection 5-30 10-20 0.55-1.10
Black MK-10 Black Precision inspection Less than 3 2-10 0.95-5.00
Black MK-15 Black Precision inspection 2-5 2-20 0.15-1.40
White MS-30 Gray General inspection 5-30 10-20 0.70-1.40

Aerosol type

Aerosol cans in which a correct amount of Black magnetic particle MK-15 is suspended in an oil.

Dry type

The dry type is used by spraying with air on the surfaces of the tested objects. Apply this type to the dried surface.

COLOR TYPE COLOR TONE PARTICLE SIZE(μm)
Red MA-100 Reddish Brown 5-50
MA-200 Reddish Brown 5-30
MA-100B Reddish Brown 40-100
Black MK-300 Black 30-50
White MS-200 Gray 5-50
MS-300 Gray 5-40
MS-400 Gray 5-30
MS-300M Gray 40-100

Remarks: High-temperature white magnetic particle MS-200H………Designed specially for up to 500℃ tested objects.

Transfer premixed type(Aerosol)

Black magnetic particles, MK-10, is suspended in a fast drying solvent. Ideal for transferring and recording the defects.

Container

Magnetic particles-1kg Can, 5kg can
Conditioners, Rust preventives-3.8 L Can, 18 L Can
MAGNATRON OIL-18 L Can

Water conditioner

Blendex

To use magnetic particles in water, any conditioner should be applied. Be sure to prepare particles and the conditioner, Blendex, into a paste form before putting into water.

TYPE APPEARANCE RECOMMENDED CONCENTRATION FEATURES
Blendex-B Light milky white, viscous liquid 0.5-2.0% to water Regular type, Well suspended.
Blendex-D Non-foaming, use when bubbles foaming during circulation of magnetic particle solutions.
Blendex-RH 3-5% to water Strong rust-prevention. Can paint directly the parts without cleaning after inspection.

MAGNATRON OIL(Oil for particle suspension)

Use this oil product instead of kerosine to suspend magnetic particles in oil. Due to its flash point of above 94℃, it is less flammable than kerosine at normal temperature and even odorless.

Resmine(Antirust )

Adding this rust preventive product to a magnetic particle water solution prevents the tested objects from rusting for several days after inspection. (Adjust the amount depending on your requirement.)
Resmine・・・・・Used for general steel materials. Add 1-5% to magnetic particle suspension.
Resmine-C・・・Suitable for casting materials. Add 0.5-5% to magnetic particle suspension.

Read More

Electromagnetic yoke “HANDY MAGNA”

To perform magnetic particle inspections conveniently, HANDY MAGNA is an excellent means. Simply contacting magnetic poles directly with inspection objects and applying magnetic particles with the switch held down detects any defects easily. Various types are provided to satisfy inspection requirements.

Download Catalog

Portable Electromagnet Yoke

Models

A-1 Standard type. Mainly used for welding. With an universal yoke.
A-2 Small and compact type of A-1 type. Useful for long time inspections. Universal yoke is an option.
A-4 Variable yoke type. Used for multi-purposes and applications.
A-6 Small and compact type of A-4 type.
TE-2 Spot type. Ideal for local inspections and for carrying.
TE-3 Model TE-3 is the best for a turbine blade inspection.
HM-52L Compact and lightweight for fillet weld
HM-76 Compact and lightweight

Configuration

  • Body (with a micro switch)
  • 5m power cable (3-core, two-type rubber cap tire cable)
  • Steel carrying case

Features

  1. The AC continuous method achieves higher ability to detect any surface defects by the skin effect.
  2. The yoke type, which suppresses a current flowing directly into the tested objects, avoids any possibility of sparking.
  3. Small, compact, and 100V power supply (AC) suitable for portable use.
  4. Yokes allow the user to use HANDY MAGNA for any shape tested objects.
  5. Water-proof switches minimize risks of rare short or shocks to human bodies when wet particles are used.
  6. For A-1, A-2, and A-6, their bodies have been connected directly to cable connection so that their strength and water-proofing property are improved.

SPECIFICATIONS

TYPE A-1 A-2 A-4 A-6 TE-2 HM-52L HM-76
Current AC100V 50/60Hz(200V and other Voltage can be option.) AC100V 50Hz
Rated current(A) 50Hz 4 2.5 4 3.5 1.2 1.4 1.2
60Hz 3 2.3 3 2.3 0.7 – –
Magnetic flux(mWb) 50Hz 0.80 0.60 0.70 0.57 0.30 0.32 0.35
60Hz 0.70 0.55 0.57 0.48 0.27 – –
Magnetic electrode distance
(mm)		 140 110 140 110 70 52 76
Size(WxDxH)mm 235x50x135 193x46x115 235x50x183 193x50x151 115x52x70 180x43x96 134x43x97
Magnetic electrode Cross-Section Dimensions(mm) 25×25 20×20 25×25 20×20 15×15 15×15 15×15
Weight without cable(kg) 3.2 2.0 3.6 2.0 1.2 1.0 1.0

Duty cycle

-1,A-2, and A-6・・・・・・・・・・・・・・・・・70%(5sec ON, 2sec OFF)
TE-2,HM-52L,HM-76・・・・・・・・・・・・・・50%(5sec ON, 2sec OFF)

Lifting power

(excluding TE-2)・・・・・・・・above 10 pounds

Voltage and frequency are fixed per your requirements.

4-pole electromagnet

Developed specially for inspections on the bottoms of tanks and the welds of pressure vessels. The rotating magnetic field enables the defects in all directions to be detected. Since this type can check for any defect while running, testing performance is improved.

SPECIFICATIONS

TYPE HM-4AX HM-5AX
Magnetizing power(AT) 2400×2 3500×2
Effective inspection wide 80mm 100mm
Body weight 4kg 8kg
Duty cycle 5 sec. ON
5 sec. OFF		 5 sec. ON
5 sec. OFF
Read More

Magnetic particle inspection machine

Description

MAGNASTAR consist of various types of components required for magnetic particle inspections such as a magnetizing power supply, a different type of magnetic particle inspection equipment, and a demagnetizer. Select out the desired type appropriate for your inspection objects and inspection requirements. EISHIN also designs and manufactures special-purpose magnetic particle inspection equipment.

Specifications

Magnetizing power supply

To meet all of varied needs, a wide range of types are provided from the portable type to the large system.

Portable type

Designed to be small and compact. This type can be carried easily, so it is useful for outside inspections or when the inspection location is undefined.

Thyristor type

Power supply using the thyristor phase control system. This type provides both of AC and DC magnetic outputs, and a built-in AC automatic attenuation demagnetizer (Models SA-50 and 60 provide a DC pole reversing automatic attenuation demagnetizer as well). Suitable for a wide range of applications from prod magnetizing to large automatic systems.

TDF type

This largest-sized type provides both of AC and DC (three-phase full-wave rectification) outputs and a built-in AC automatic attenuation demagnetizer (a DC pole reversing automatic attenuation demagnetizer as well). Mainly used for the surfaces and subsurface inspections of steel materials, large-sized parts, precise parts, etc.

Thyristor type SA-50,60

Magnetic particle inspection equipment

To meet all of varied needs, a wide range of types are provided from the portable type to the large system.

Training type

Designed specially for training or magnetization testing.

SA type

Standard type and commonly used.

Immersion type

In this type, to perform inspections, the tested materials are immersed into a particle solution. Two types are provided : Model DHS, electrode-pressing type, and Model DHT, clamped type.

Duovec type

Performs inspections of the inspection objects in the longitudinal and circumferential directions simultaneously at one magnetizing operation.

TDF type

In conformance to MIL Standards, designed specially for detecting of aircraft and precise parts.

SA-40H

Demagnetization

Demagnetizing power supplies/power units

For complicated-shape parts, it has been very difficult to demagnetize down to 3 gausses or lower so far. This type has overcome such a problem. Combination of a power supply and various types of coils enables the user to select the desired demagnetizing technology.

Demagnetizer

There are many technologies for demagnitization. Encircling coil or box-type demagnetizers are commonly used. With the encircling coil type, demagnetization can be done in several ways satisfying the user’s needs. The box-type is useful for inspections on small-article parts and thin steel sheets.

SPD-80H

BOX-type

Read More

ec1 Dot Peen Marking Machine

PRESENTATION VIDEO

Description

The ec1 column-mounted dot peen marking system is suited for table top marking in any industrial environment. Ideal for marking small to medium sized parts, its working speed, consistent quality, and reliable accuracy make it a highly efficient marking machine. Capable of marking plastics and hardened steel (up to 62HRC), the ec1 benchtop marking machine uses a solenoid actuated stylus which does not require a separate pneumatic system and can be combined with optional marking equipment (d-axis or plate). It requires little maintenance and consumables, and is a reliable and sturdy marking system suitable for a multitude of applications.

The ec1 software was created to be as simple as possible using an industrial keyboard covered with a membrane and a large color screen. This software has been completely rethought for easy control and greater intuitiveness. It offers easy and quick creation of all your marking files directly on the controller.

Specifications

MECHANIC FEATURES

Marking Window: 120 x 100 mm
Weight: 16kg
Column Stroke: 280 mm
Stylus: Carbide
Rotary Axis (option): For Parts up to 150 mm

ELECTRONIC FEATURES

Integrated directly into the controller ec1, the included software is easy to configure and program. It can also be programmed from a PC via SICTOOLS, compatible on any PC with a Windows-based Operating System.

LCD Screen: 95×54 mm
Keyboard: Integrated QWERTY Keyboard
Power: 100W
Power Supply: 110 V or 220V (50-60Hz)

STEERING SOFTWARE

Use the ec1 software to manage marking files from any PC with a Windows-based Operating.

File Capacity:
> 1000 Files
Memory: 100 Mo
Alphanumeric Characters: Serial Number, Date Coding
Logos: Download from a PC or a USB key
Fonts: 5×7, Arial, Courier, OCR, OCR_BOLD and OCRA
Marking Orientation: Linear, Radial ,Angular, datamatrix, logo, mirror
Character Size: From 0.1mm to 99mm
Depth: Up to 0.3 mm
Resolution Between Dots: 0.22 mm
Password: 2 Security Levels
Software: 15 Languages
Historic: Anti-duplication

COMMUNICATION

Ports: RS232, USB
PC based software: Creation and transfer: backups, logos

OPTIONS

Read More

UV Lamp for NDT Black light Model LV-9

Description

UV-LED lamp . Effective for line inspection.

Ilumination distribution image

Specifications

Specifications
Power consumption 170VA
Fan Fanless
Dimensions LV-6    ：    W1,080  ×  D171  ×  H188
LV-9    ：    W 630  ×  D171  ×  H188
LV-18  ：    W1,260  ×  D171  ×  H188
LV-24  ：    W1,680  ×  D171  ×  H188
Weights LV-6    ：7.9kg
LV-9    ： 8.2kg
LV-18  ：14.3kg
LV-24  ： 21.2kg
UV intensity LV-9,18,24：6,500μW/cm2 at 600mm
LV-6：2,300μW/cm2at 600mm
Power source voltage 100～240V 　50Hz / 60Hz
Power source current 1.7A
Power cable Primary 3m, Secondary 5m
Read More

UV Lamp for NDT Black light Model S-35LC

  • Eishin & J.N.S. (2003) UV-LED Black Light is specialized in performance necessary for non-destructive inspection.

Description

  • Wide cover range. When distance 200 or 400mm, 170 width covered.
  • No irradiation unevenness. By original optical design, irradiation within the limits does not have change of extreme illumination.
  • Does not Halation. Attached halation cut filter.
  • White Lamp. LED White lamp attached

Specifications

Specifications
Dimensions 300W×185H×204D mm
Weight 4.0kg
Lamp head dimensions φ92×169×237 mm
Lamp head weights 0.6kg
UV intensity 4,500μW/cm2 at 381mm
Power source voltage 100V±10%
Power source current 0.5A
Power cable Primary 2.5m, Secondary 3m
V cut filter Attached
Read More

UV Lamp for NDT Black light Model ZB-365J

Description

Portable high-power flashlight come with 2 rechargeable batteries. Provides approx. 3hours of continuous inspection. Choice of range and ultraviolet light intensity by the Dimming function. Standard equipped with “synthetic quartz glass filter ” cuts unnecessary visible light on inspection.

band pass filter

Specifications

Specifications
Dimensions Φ38(Head) Φ25(Grip)×140 mm
Weight 180g
UV intensity
(WD=Working Distance) 		 19,990μW/cm2over　WD=381mm
Visible light component Less than 10Lx at WD=30-381mm
Power source Li-ion Battery (18650) ×1
Filter Band pass filter
Read More
